NVIDIA DGX A100

NVIDIA DGX A100

  • SKU: TCSDGXNXTA1H-PB

Where to Buy Request a Quote

  • Description

    NVIDIA DGX A100

    The Universal System for AI Infrastructure

    The Wolrd's First AI System Built on NVIDIA A100

    Part of the NVIDIA DGX™ platform, NVIDIA DGX A100 is the universal system for all AI workloads, offering unprecedented compute density, performance, and flexibility in the world’s first 5 petaFLOPS AI system. Featuring the NVIDIA A100 Tensor Core GPU, DGX A100 enables enterprises to consolidate training, inference, and analytics into a unified, easy-to-deploy AI infrastructure that includes direct access to NVIDIA AI experts.


    Highlights

    GPU's

    8x NVIDIA A100 80B Tensor Core GPU's

    GPU Memory

    640GB total

    Performance

    5 petaFLOPS AI

    10 petaFLOPS INT8

    NVIDIA NVSwitches

    6

    System Power Usage

    6.5 Kw max

    CPU

       Dual AMD Rome 7742, 128 cores total, 2.25 GHz (base), 3.4 GHz (max boost)

    System Memory

       2TB

    Networking

    Up to 8x Single-Port NVIDIA ConnectX-7 200Gb/s InfiniBand Up to 2x Dual-Port NVIDIA ConnectX-7 VPI 10/25/50/100/200 Gb/s Ethernet

    Up to 8x Single-Port NVIDIA ConnectX-6 VPI 200Gb/s InfiniBand Up to 2x Dual-Port NVIDIA ConnectX-6 VPI 10/25/50/100/200 Gb/s Ethernet

    Storage

    OS : 2x1.92TB M.2 NVME drives Internal Storage : 30TB (8x3.84TB) U.2 NVMe drives

    Software

    DGX OS / Ubuntu / Red Hat Entreprise Linux / Rocky - Operating System NVIDIA Base Command - Orchestration, scheduling, and cluster management NVIDIA AI Entreprise - Optimized AI software

    Support

    Comes with 3-year business standard hardware and software support

    System Weight

    271.5 lbs (123.16kgs max)

    Packaged System Weight

    359.7 lbs (163.16 kgs) max

    System Dimension

    Height : 10.4 in (264.0mm)

    Width : 19.0 in (482.3mm) max

    Length : 35.3 in (897.1mm) max

    Operating Temperature Range

       5°C to 30°C (41°F to 86°F)
